Application data/communication
1. Independent Disk
2. Optical Drive
3. Workstation
4. Server
5. Storage shelf
Features and benefits
1. The transmission rate is 6Gbps.
2. Comply with SAs3.0 specification.
Mechanical behavior
1. Mating power and mating power
Conditions: EIA 364-13. Insert and extract at a speed of 25 mm/min.
Mating power: 50N max
Demoulding force: minimum 20N
2. Durability:
Condition: Eia364-09. Matched and unmatched connectors have 25 cycles, 200 times per hour.
There is no physical damage and should meet the requirements of subsequent tests.
Electrical performance
1. Contact resistance
Situation: Environmental Impact Assessment 364-23. The main body matches the contacts assembled in the housing to a maximum of 20 MV. The maximum open circuit is 100Ma.
30 moms are the maximum, initially paired per contact.
2. Withstand medium voltage
Situation: Environmental Impact Assessment 364-20. Method B. Tests between adjacent mated and unpaired connector components. At sea level, the insulator should be able to withstand 500 volts for 1 minute.
No flashover, no sparks, no excess leaks, and no malfunctions.
3. Insulation resistance
Condition: EIA 364-21, received
